Quad QC-24P Phono Stage
Free UK Delivery
Quad QC-24P Phono Stage
Quad's QII (or 'Quad 2') series is based on the original Quad II amplifier, built by the company's founder Peter Walker in 1953, but now seeing the integration of finer components and materials, more intricate yet effective circuit integrations and a more precise manufacturing process. The QII series features some of the most refined sounding valve pre/power combinations on the market today, retaining the genuine heritage and craftsmanship that Quad has preserved over 80 years of designing and engineering quality hifi.
The Twenty Four P was designed and engineered specifically for vinyl enthusiasts by Quad valve expert Tim DeParavicini, honing years of expertise in the analogue domain. In addition to superior warmth and dynamic prowess, the 24P is also greatly flexible with a toggle switch for moving magnet/moving coil, and a choice of direct full level output or variable level output.
Who is Quad?
Quad is a highly renowned manufacturer of quality hifi electronics and loudspeakers, having developed award-winning audiophile-standard products standard for over 80 years, their highly acclaimed reputation is well-earned. The company originally built speakers for public address, moving onto domestic hifi following the end of the war. The first commercially available products were the Quad 22 Pre-amp and Quad II Monoblock Power Amplifiers, both of which were on the market for ten years to great success.
Valve complement | 4 x 6111 twin triode |
Total Harmonic Distortion | <0.08% (A-weighted) |
Hum and Noise | Better than 60dB |
Input Impedance | Moving Magnet 47kohms |
Input Impedance | Moving Coil# 10 ohms |
Stage Gain (high sensitivity) | 1.3mV (MM)/130uV (MC) |
Stage Gain | Medium Sensitivity 2.6mV (MM) / 260uV (MC) |
Stage Gain | Low Sensitivity 5.2mV (MM) / 520uV (MC) |
Nominal Output Level | (ref 5.2mV, MM, Low) 1V |
Inputs Selectable | MM/MC cartridge |
Outputs | 1 x Fixed line level, 1 x Variable line level |
Power Consumption | 15VA maximum |
Dimensions | (H x W x D) 90 x 220 x 300mm |
